Camera
|
|
Image Sensor
|
4 × 1/2.8” Progressive Scan CMOS
|
|
Max. Resolution
|
5MP, 2592(H) × 1944(V)
|
|
Electronic Shutter
|
Auto/Manual, 1/5 to 1/20,000s
|
|
Min. illumination
|
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
|
|
Day & Night
|
IR cut filter
|
|
Wide Dynamic Range
|
True WDR
|
|
Angle Adjustment
|
Pan: -180˚ to 180˚, Tilt: 0˚ to 130˚, Rotation: 0˚ to 355˚
|
|
Lens
|
|
Lens Type
|
Varifocal lens, Motorized focal
|
|
Iris
|
DC- Iris
|
|
Focal Length
|
2.7 to 13.5 mm
|
|
Max. Aperture
|
F1.6
|
|
Field of View (FOV)
|
H: 95.6° to 26.9°, V: 65.4° to 20.5°
|
|
DORI Distance
|
|
Detect
|
68 to 195 m (223.1 to 639.8 ft)
|
|
Observe
|
27.2 to 78 m (89.2 to 255.9 ft)
|
|
Recognize
|
13.6 to 39 m (44.6 to 128.0 ft)
|
|
Identify
|
6.8 to 19.5 m (22.3 to 19.5 ft)
|
|
DORI (Detect, Observe, Recognize, and Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances.
|
|
Illuminator
|
|
Illuminator Type
|
IR
|
|
Illumination Distance
|
IR distance up to 40 m (131.2 ft)
|
|
Illumination On/Off Control
|
Auto/Manual
|
|
IR Wavelength
|
850 nm
|
|
Intelligent Analytics
|
|
Multi-Object Detection
|
Supports face, human, vehicle detection and capture.
Supports multiple frame modes: Full Frame, Four-corner Frame, and Mosaic.
|
|
Intelligent Analysis
|
Intrusion, Smart motion detection, Single line crossing, Double line crossing, Loitering, Wrong-way detection, Illegal parking, Enter area, and Leave area
Support alarm triggering by specified target types (human and vehicle)
|
|
People Counting
|
Support
|
|
Video and Audio
|
|
Streaming Capability
|
3 Streams
|
|
Stream/Frame Rate
|
Stream1: 2592 × 1944, 2592 × 1520, 1920 × 1080, 1280 × 720 @ 25/30fps
Stream2: D1, VGA, CIF @ 25/30fps
Stream3: VGA, CIF, QVGA @25/30fps
|
|
Bit Rate Control
|
CBR/VBR
|
|
Bit Rate
|
Stream1: 200 kbps to 12 Mbps
Stream2: 100 kbps to 6 Mbps
Stream3: 100 kbps to 3 Mbps
|
|
Smart Encoder
|
Support
|
|
Region of Interest (ROI)
|
Support
|
|
Audio Compression
|
G.711 A-law, G.711 μ-law, RAM PCM
|
|
Audio Bit Rate
|
64 Kbps (G.711), 128 Kbps (RAW_PCM)
|
|
|
|
Image Adjustment
|
Brightness, Sharpness, Contrast, Saturation adjustable
|
|
Scene Setting
|
Indoor, Outdoor, Mirror, Corridor Mode
|
|
Exposure Mode
|
Auto, Manual, Shutter priority
|
|
White Balance
|
Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual
|
|
Day/Night Setting
|
Auto, Day, Night, Timer
|
|
Noise Reduction
|
2D/3D DNR
|
|
Image Enhancement
|
WDR, HLC, BLC, Defog
|
|
Privacy Masking
|
Up to 4 × 4 areas
|
|
Event
|
|
Alarm Triggers
|
IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection
|
|
Event Actions
|
Alarm record, FTP upload, SMTP upload, Alarm output, Audible alarm output
|
|
Network
|
|
Protocols
|
IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast
|
|
Interoperability
|
ONVIF (Profile S/T/G/M), SDK, CGI
|
|
Max Concurrent Streams
|
10 channels
|
|
User/Host Level
|
32+ users, 3 levels: Administrator, Operator, Media user
|
|
Security
|
IP address filter, HTTPS, Illegal login lock, IEEE 802.1x
|
|
Web Viewer
|
<IE11, Chrome, Firefox, Microsoft Edge
|
|
Interface
|
|
Network Interface
|
1 Ethernet (100/1000 Base-T) RJ-45 Connector
|
|
Built-in Microphone
|
Support
|
|
Audio Interface
|
1ch Input, 1ch Output
|
|
Alarm Interface
|
4ch Input, 2ch Output
|
|
RS-485
|
1 RS-485
|
|
CVBS Interface
|
1 BNC interface
|
|
SD Card Slot
|
Built-in, up to 1 TB
|
|
Reset Button
|
Support
|
|
General
|
|
Language
|
English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English
|
|
Power Supply
|
12 VDC (-15% to +25%) / PoE+ (802.3at)
|
|
Power Consumption
|
Typical: 10.8 W (12 VDC) / approx. 13.5 W (PoE)
Max (IR on): 20.2 W (12 VDC) / approx. 25.3 W (PoE)
|
|
Operating Temperature
|
-40°C to 60°C (-40°F to 140°F )
|
|
Operating Humidity
|
Less than 90% RH
|
|
Ingress Protection
|
IP67, IK10
|
|
Certifications
|
CE-EMC
- EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4
FCC 47 CFR Part 15 Subpart B
|
|
Material
|
Aluminum alloy body, bubble: plastic
|
|
Dimensions
|
Φ282 × 206.3 mm (φ11.1 × 8.12 inch) , (Bracket not included)
|
