VIVOTEK IB9383-HV
Cámara IP tipo bala. 5MP @30 fps, Trend Micro loT Security, Smart VCA, análisis inteligente de objetos de visión, WDR Pro, IP66/IK10, 30M IR
Cámara IP tipo bala varifocal IR WDR de 8 MP
Image Sensor 1/2.8” Progressive Scan CMOS
Electronic Shutter Auto/Manual, 1/5 ~ 1/20,000s
Min. illumination Color: 0.01 Lux @ (F1.2, AGC ON) ,
B/W: 0 Lux @ (IR LED ON)
S/N Ratio 55dB
Day/Night Mode Auto(ICR)/Day/Night/Time
Wide Dynamic Range True WDR
IR Range Up to 40 m (131.2 ft)
IR On/Off Control Auto/Manual
Pan/Tilt/Rotation Range Pan: 0˚ ~ 360˚, Tilt: 0˚ ~ 90˚, Rotation: 0˚ ~ 360˚
Lens Type Motorized focus
Iris Fixed Iris
Focal Length 2.7 ~ 13.5 mm
F Number F1.6
Angle of View H: 98.1°~30.9°, V: 52.6°~17.3°
Max. Resolution 8MP (3840×2160)
Streaming Capability 3 Streams
Stream/Frame Rate Stream1: 3840×2160, 2592×1944, 2592×1520, 2560×1440, 2048×1536, 1920×1080, 1280×720 @ 25/30fps
Stream2: D1, VGA, 640×360, CIF, QVGA @ 25/30fps
Stream3: VGA, CIF, QVGA @ 25/30fps
Bit Rate Control CBR/VBR
Bit Rate Stream1: 100kbps~16Mbps
Stream2: 10kbps~6Mbps
Stream3: 10kbps~3Mbps
Image Enhancement HLC / BLC / Defog / WDR
White Balance Auto
Gain Control Auto/Manual
Noise Reduction 2D/3D DNR
Aisle Mode Support
Smart IR Support
Mirror Support
Region of Interest Off/On (8 Zone, Rectangle)
Motion Detection Support
Privacy Masking Support
Smart Function Support face, human, vehicle detection
Intelligent Detection Perimeter, Single Virtual Fence, Double Virtual Fences, Loiter, People Counting
Compression G.711, RAW_PCM
Bit Rate 8kbps, 16kps, 64kbps
Protocols IPv4/IPv6, 802.1x, HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ARP, SNMP, TLS/SSL
Interoperability ONVIF, SDK, CGI
Streaming Method Unicast
Max. User Access 10 Users
Web Viewer <IE11, Chrome, Firefox, Microsoft Edge
Management Software SunView
Network Interface 1 Ethernet (10/100 Base-T) RJ-45 Connector
Audio Interface 1ch Input, 1ch Output
Alarm Interface 1ch Input, 1ch Output
Reset Button Support
Built-in Micro SD slot Yes, up to 256GB
Power Supply DC12V/POE (IEEE 802.3af)
Power Consumption Max 8.5 W
Operating Temperature -40°C ~ 55°C (-40°F ~ 131°F )
Operating Humidity Less than 90% RH
Ingress Protection IP67
Certifications CE/FCC
Casing Metal
Dimensions 232 × 80 × 80mm (9.13" × 3.15" × 3.15")
Net Weight 0.81 kg (1.79 lb)
