Sunell SN-IPR5122BZBN-M
    SUNELL

    Sunell SN-IPR5122BZBN-M

    Cámara IP tipo bullet, 2MP, IP67 IR 40m

    Contáctenos acerca de este producto

    Contacto de Sunell SN-IPR5122BZBN-M

    • 1/2.8” progressive scan CMOS
    • 2.8~12mm manual lens
    • Max resolution 1920×1080 @30fps
    • Support intrusion and line crossing based on human detection
    • DWDR, 3D DNR, HLC, BLC, Defog
    • IR distance up to 40m
    • 12V DC/PoE power supply
    • IP67

    Detalle de productos

    Camera

    Image Sensor 1/2.8” Progressive Scan CMOS

    Max. Resolution 1920(H)×1080(V)

    Electronic Shutter Auto/Manual, 1/5 ~ 1/20,000s

    Min. illumination Color: 0.1 Lux @ (F1.2,AGC ON) ,

    B/W: 0 Lux @ (IR LED ON)

    S/N Ratio 55 dB

    Day/Night Auto(ICR)/Day / Night

    Wide Dynamic Range DWDR

    IR Range Up to 40 m (131.2 ft)

    IR On/Off Control Auto/Manual

    Pan/Tilt/Rotation  Range Pan: 0˚ ~ 360˚, Tilt: 0˚ ~ 90˚, Rotation: 0˚ ~ 360˚

    Lens

    Lens Type Manual focal

    Iris Fixed Iris

    Focal Length 2.8 ~ 12 mm

    F Number F1.6

    Angle of View H: 98.6° ~ 30.6°, V: 51.1° ~ 17.2°

    Video

    Streaming Capability 2 Streams

    Stream/Frame Rate Main Stream: 1920×1080, 1280×720 @ 25/30fps

    Sub Stream: 704×576, 640×360, 480×360, 352×288 @ 25/30fps

    Bit Rate Control CBR/VBR

    Bit Rate Main Stream: 128kbps ~ 4096kbps

    Sub Stream: 16kbps ~ 1536kbps

    Image Adjustment Brightness/Sharpness/Contrast/Saturation

    White Balance Auto/Manual

    Mirror Support

    Noise Reduction 2D/3D DNR

    Image Enhancement WDR/HLC/BLC/Defog

    Motion Detection Support

    Privacy Masking Support

    Network

    Protocols IPv4, RTSP/RTP/RTCP, TCP/UDP, HTTPS, DHCP, DNS, DDNS, UPNP, ICMP, IGMP, NTP, SMTP, 802.1x, SNMP

    Interoperability ONVIF, SDK

    Streaming Method Unicast

    Max. User Access 4 Users

    Web Viewer <IE11, Chrome, Firefox, Microsoft Edge

    Management Software SunView

    Smart Function

    Human Detection Support

    Smart Function Perimeter, Single Virtual Fence

    Interface

    Ethernet 1 Ethernet (10/100 Base-T) RJ-45 Connector

    Storage Built-in Micro SD slot, up to 256GB

    Reset Button Support

    Electrical

    Power Supply DC12V/POE (IEEE 802.3af)

    Power Consumption Max 8.5 W

    Operating Temperature -35°C ~ 50°C (-31°F ~ 122°F )

    Operating Humidity Less than 90% RH

    Ingress Protection IP67

    Certifications CE/FCC

    Casing Metal

    Dimensions 232 × 80 × 80mm (9.13" × 3.15" × 3.15")

    Net Weight 0.73 kg (1.61 lb)
